Advanced 10W power output and constant light intensity
The 5W LED brings longer service life with silent and comfortable operation.
Three mode presets:
F:FAST – full power all the time
R:RAMP- gradually increasing power in first 2 seconds, then full power till ends
P:PULSE – 0.2 second interval with full power for 0.8 second
Longer time needed for PULSE mode. User should follow the original instructions of the composite when curing.
6 curing time presets (5, 10, 20, 30, 40 or 50 seconds.)
Guideline for the operatiom time:
5W |
Time |
5 sec. |
10 sec. |
20 sec. |
30 sec. |
40 sec. |
(Intensity about 1500) |
Depth |
3.5 mm |
4.2 mm |
5.4 mm |
6.2 mm |
6.7 mm |
The built-in digital intensity meter
The built-in digital intensity meter in the charging station also provides instant output testing
Durability and reliability
Enjoy the long-lasting over 20,000 hours LED useful life and the autoclavable light guide for better reliability
